WHEEL RAKE/V-RAKE MODELS(2, 4, 6, 8, & 10 WHEEL MODELS)M&W1020 South Sangamon Ave.Gibson City, Illinois 60936217-784-4261Published 11/04 478

6SAFETYWARNING!Transport only at safe speeds. Serious accidents and injuries canresult from operating this equipment at unsafe speeds. Understand t

7SAFETYWARNING! Periodically inspect all moving parts for wear and replace whennecessary with authorized service parts. Look for loose fasteners,worn

8SAFETYWARNING! Be particularly careful when transporting the Implement with the Tractor. Turn curves or go uphills only at a low speed and using a g

9In addition to the design and configuration of this Implement, including Safety Signs and Safety Equipment,hazard control and accident prevention are

10Your M&W Rake may come unassembled or partially assembled as required using the following instructions.1. Install the Sector Support (8) on the

115. Insert the Main Frame (33) into the Floating Arm (26). Lock the in place by installing the Lever Plate (16) onthe floating arm and secure with

12CONNECTING THE RAKE TO THE TRACTORWith the rake supported by the wheel teeth and the stand, back the tractor to the rake and connect the tractor to

13WORKING POSITIONSPull the pin in the sector support and turn the main frame to the right and rotate the arms so the wheels arepositioned as shown be

14USING LEFT AND RIGHT-HAND MODELS TO MAKE A V-RAKE1. Install the Tool Bar Frame (1) to the tractor 3-point linkage using a forklift or crane. Raise

15TROUBLESHOOTINGPROBLEM PROBABLE CAUSE SOLUTIONHay carrying over on the wheels. Teeth not polished. Operate rake on gravelsurface for a short distanc

TO THE OWNER/OPERATOR/DEALERAll implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-mindedoperator wh

LIMITED WARRANTY1. LIMITED WARRANTIES1.01.M&W warrants for one year from the purchase date to the original non-commercial, governmental, or m

To keep your implement running efficiently and safely, read your manual thoroughly and follow these directions andthe Safety Messages in this Manual.

Printed U.S.A. 4782C

M&W®1020 S. Sangamon Ave.Gibson City, IL 60936-9907Please fold (do not tear), tape, and drop in any mailbox.PLEASE FILL OUT OWNER WARRANTY REGIST

• I have informed the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable, reviewed the contents of the Opera

• I have informed the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable, reviewed the contents of the Opera

• I have informed the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable, reviewed the contents of the Opera

In order to reduce accidents and enhance the safe operation of mowers, Alamo Group Ag Division, incooperation with other industry manufacturers has de

Alamo Group Ag. Division is willing to provideone (1) AEM Mower Safety Practices VideoPlease Send Me: VHS Format – AEM/FEMA Mower Operator Safety Vide

1Specifications ...

2SAFETY INSTRUCTIONSWhen ordering parts, please specify the part number and the name of the part shown in the parts section. Pleasegive the serial nu

3SAFETYA safe and careful operator is the best operator. Safety is of primary importance to themanufacturer and should be to the owner/operator. Mos

4SAFETYREAD, UNDERSTAND, and FOLLOW the following SafetyMessages. Serious injury or death may occur unless care istaken to follow the warnings and

5SAFETYDANGER!Never allow children to operate or ride on the Tractor or Implement. (SG-11)WARNING!Do not mount the Tractor while the tracto
